PEPPERL+FUCHS KFD2-CR-Ex1 30-200

Get a Price/Quote

MOQ : 1 Piece

PEPPERL+FUCHS KFD2-CR-Ex1 30-200 Specification

Control Type
Relay Control Module

Mounting Type
35 mm DIN rail mounting

Features
SIL 2 (IEC 61508), galvanic isolation, pluggable terminals, LED indicator

Automation Grade
Industrial Grade

Remote Control
Yes

Connectivity Type
Terminal connection

Load Capacity
5 A at 230 V AC / 30 V DC

Cable Length
Dependent on application

Weight
Approximately 150 g

IP Rating
IP20

Frequency
50/60 Hz

Application
Signal isolation and relay control in hazardous areas

Phase
Single phase

Material
Polycarbonate housing

Power
<1 W power consumption

Temperature
-20C to +60C operating temperature

Voltage
20 V DC to 30 V DC

Dimensions (HxWxD)
119 mm x 20 mm x 107 mm

Enclosure Type
Standard ribs, snap-on

Status Indication
LED (yellow) for relay status

Relay Output
1 NO/NC configurable

Input Signal Type
Digital input (controller/PLC)

Response Time
<15 ms

Model Number
KFD2-CR-Ex1.30-200

Intrinsic Safety
Yes, certified for Class I, Div 1/Zone 0/1

Storage Temperature
-40C to +80C

PEPPERL+FUCHS KFD2-CR-Ex1 30-200 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About PEPPERL+FUCHS KFD2-CR-Ex1 30-200

PEPPERL+FUCHS KFD2-CR-Ex1 30-200

The KFD2-CR-Ex1.30200 supplies a 2-wire transmitter in the hazardous area with power. 2-wire transmitters function exclusively with a 4 mA ... 20 mA signal. At least 17.6 V is available for the transmitters at a measurement current of 20 mA. The input circuit's current is transferred to the safe area.

Certified Intrinsic Safety for Hazardous Environments

The KFD2-CR-Ex1.30-200 is designed for use in hazardous areas with stringent safety requirements. Certified for Class I, Div 1/Zone 0/1, it offers intrinsic safety and galvanic isolation, ensuring both equipment and personnel protection in critical industrial applications. This makes the module ideal for industries where safety is paramount, such as oil and gas, chemical, and pharmaceutical sectors.

Versatile Installation and Configuration

Featuring a compact form factor (119 mm x 20 mm x 107 mm) and DIN rail mount compatibility, installation is rapid and straightforward. The relay output (NO/NC) is configurable for maximum flexibility, while pluggable terminals and a clear LED status indicator simplify maintenance and monitoring. Its polycarbonate housing and IP20 rating provide sturdy yet lightweight protection for a wide range of setups.

FAQ's of PEPPERL+FUCHS KFD2-CR-Ex1 30-200:

Q: How can the KFD2-CR-Ex1.30-200 be installed in my industrial setup?

A: The module is designed for easy mounting on a standard 35 mm DIN rail. With pluggable terminals and a slim polycarbonate housing, it integrates seamlessly into control panels, saving space and ensuring quick connection to controllers or PLCs.

Q: What types of signals are compatible with the KFD2-CR-Ex1.30-200 input?

A: This relay control module accepts digital input signals from controllers or PLCs, making it suitable for automation systems requiring reliable signal isolation and relay operation.

Q: When is it beneficial to use this relay control module?

A: The KFD2-CR-Ex1.30-200 is most beneficial when you need to safely transmit and isolate digital control signals in hazardous or classified areas, meeting safety integrity level requirements (SIL 2) for critical industrial processes.

Q: Where can the KFD2-CR-Ex1.30-200 be deployed?

A: It is suitable for hazardous environments such as oil refineries, chemical plants, and pharmaceutical facilities where intrinsic safety and reliable signal isolation are essential. The device is widely distributed and supported in India.

Q: What are the power and load handling capabilities of this module?

A: The device operates on 20-30 V DC with less than 1 W power consumption. It supports load capacities up to 5 A at 230 V AC or 30 V DC, suitable for controlling a wide range of industrial devices.

Q: How does the LED status indication assist with operations?

A: A yellow LED provides clear relay status at a glance, allowing operators to quickly verify whether the relay is energized, helping with diagnostics and improving system transparency during operation.
