Instantaneously Under Voltage Vag21zg8382g(M)
Instantaneously Under Voltage Vag21zg8382g(M)
images Send Inquiry
Request To Call Back

Instantaneously Under Voltage Vag21zg8382g(M)

Get a Price/Quote
MOQ : 1 Piece

Instantaneously Under Voltage Vag21zg8382g(M) Specification

  • Coil Power
  • 1.2W
  • Coil Voltage
  • 220V AC
  • Dielectiric Strength
  • 2000V AC/min
  • Protect Feature
  • Instantaneous Under Voltage protection
  • Contact Form
  • SPDT
  • Contact Material
  • Silver alloy
  • Contact Resistance
  • ≤100mΩ
  • Ambient Temperature
  • -5°C to +40°C
  • Power Consumption
  • <2W
  • Working Temperature
  • -5°C to +40°C
  • Mechanical Life
  • 100,000 operations
  • Product Type
  • Under Voltage Protection Relay
  • Insulation Resistance
  • >100MΩ (at 500V DC)
  • Theory
  • Electromagnetic Relay
  • Usage
  • Industrial and commercial under voltage protection
  • Contact Load
  • 5A 250VAC
  • Operate Time
  • ≤0.2s
  • Terminal Type
  • Screw terminal
  • Rated Voltage
  • 220V AC
  • Supply Terminal
  • Single phase
  • Size
  • Standard DIN rail mount
  • Color
  • White & Blue
  • Dimension (L*W*H)
  • 83mm x 18mm x 63mm
  • Weight
  • 160g
  • Humidity Range
  • ≤85% RH
  • Response Time
  • Instantaneous (≤0.2 seconds)
  • Under Voltage Setting Range
  • 120V - 190V adjustable
  • Application
  • Single phase electrical systems
  • Mounting Method
  • DIN rail
  • Switching Capacity
  • 5A max.
  • Reset Method
  • Automatic & manual
  • Display
  • Status LED indicator
  • Standards Compliance
  • IEC60947-5-1


Instantaneously Under Voltage Vag21zg8382g(M) Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 100 Pieces Per Month
  • Delivery Time
  • 7 Days


About Instantaneously Under Voltage Vag21zg8382g(M)



Experience an Elite solution for under voltage protection with the Instantaneously Under Voltage VAG21ZG8382G(M)your Last Chance to secure exceptional performance at the lowest price. This ace device delivers dazzling protection for single-phase industrial and commercial environments, with a rapid response time of 0.2 seconds. Adjustable from 120V190V, it boasts automatic and manual reset capabilities, an intuitive status LED display, robust 5A switching capacity, and compliance with IEC60947-5-1. Its DIN rail mounting ensures effortless installation, while silver alloy contacts guarantee enduring reliability. Dont miss outprotect your systems now!

Precise Under Voltage Protection with Flexible Usage

The VAG21ZG8382G(M) is designed for seamless operation in industrial and commercial single-phase electrical systems. Install on a DIN rail and connect through screw terminals for a dependable under voltage safeguard. Adjust the protection threshold between 120V190V as needed for your specific application. Ideal for facilities requiring rapid response (0.2 seconds), it offers both automatic and manual reset methods, making it versatile for continuous or event-based protection modes.


Secure Packaging, Fast Delivery, and Broad Export Reach

Every Instantaneously Under Voltage VAG21ZG8382G(M) is securely packaged to prevent damage during transportation, ensuring pristine delivery. With a strong focus on order processing and customer satisfaction, your purchase is shipped promptly at the lowest price possible. Our service extends across key export markets including Asia, Africa, and the Middle East, meeting global demand with on-time delivery. Choose us for a reliable distributor, exporter, importer, and supplier from India.


FAQs of Instantaneously Under Voltage Vag21zg8382g(M):


Q: How is the Instantaneously Under Voltage VAG21ZG8382G(M) installed?

A: This device is designed for easy DIN rail mounting in standard electrical panels. Simply secure it in place and connect the wiring using screw terminals according to your specific system requirements.

Q: What is the adjustable under voltage setting range for this relay?

A: You can set the under voltage protection between 120V and 190V, giving you control to suit different industrial and commercial applications.

Q: When will I receive my order after placing it?

A: Order processing begins immediately after confirmation. Delivery times vary based on location, but we prioritize quick shipment and safe transportation to get your device to you as rapidly as possible.

Q: What benefits does the VAG21ZG8382G(M) offer for electrical systems?

A: It provides instant under voltage protection with a swift 0.2 second response, automatic and manual reset, and a long mechanical life of up to 100,000 operations, helping prevent costly equipment damage and downtime.

Q: How can I monitor the operational status of the unit?

A: A dedicated LED status indicator clearly displays the current functional state, making real-time monitoring simple and efficient for users.

Q: Where can the device be particularly beneficial?

A: This relay is especially beneficial in single-phase industrial and commercial electrical systems where reliable and swift voltage protection is critical, such as manufacturing plants, warehouses, and commercial complexes.
