SIEMENS 6ES7 223-1BL32-0XB0 PLC

Get a Price/Quote

SIEMENS 6ES7 223-1BL32-0XB0 PLC Specification

Automation Grade
Automatic

Control Type
Digital / Integrated

Frequency
47–63 Hz

Application
Industrial Automation, Machine Control, Process Automation

Sensor Type
Supports Digital and Analog Sensors via appropriate modules

Phase
Single Phase

Processor Type
Integrated Microprocessor

Mounting Type
DIN Rail Mounting

Cable Length
Depends on installation, Maximum 50 m for digital I/O wiring

Load Capacity
16 Digital Inputs & 16 Digital Outputs (24V DC Input, Relay/Transistor Output Type)

Drive Type
Programmable Logic Controller (PLC)

Remote Control
Yes

Speed Range
High-speed counting up to 30 kHz for select inputs

Weight
Approx. 270 g

Features
Compact design, Expandable I/O, Integrated Communication Port

Connectivity Type
RS485 (MPI/Profibus DP) Communication Port

IP Rating
IP20

Material
Plastic and Metal Housing

Power
24 V DC

Temperature
0°C to +55°C (operating)

Voltage
20.4 to 28.8 V DC

About SIEMENS 6ES7 223-1BL32-0XB0 PLC

SIEMENS 6ES7 223-1BL32-0XB0 PLC

Siemens Digital I/O Module, 16 Inputs, 16 Outputs, 50 us Off to On/200 us On to Off Step Response, 24 VDC, 4 mA, Front Connector Terminal, -20 to 60 deg C, 100 mm H x 70 mm W x 75 mm D Dimensions.

Flexible I/O Expansion for S7-200 PLCs

The SIEMENS EM 223 module seamlessly adds 16 digital inputs and 16 relay outputs to your existing SIMATIC S7-200 system, making it ideal for growing automation requirements. Its compatibility with digital and relay I/O allows integration into a broad range of industrial applications. With a space-saving design and robust build, this expansion module is well-suited for environments where reliability and scalability are essential.

Reliable Performance in Tough Environments

Certified to withstand vibrations up to 2g and shocks up to 15g/11 ms, the 6ES7 223-1BL32-0XB0 operates consistently in demanding settings. It endures ambient storage temperatures from -40C to +70C and functions reliably within 0C to +55C. With a relative humidity tolerance up to 95% and IP20 protection against solid objects, this module assures high dependability for long-term industrial usage.

FAQ's of SIEMENS 6ES7 223-1BL32-0XB0 PLC:

Q: How do I install the SIEMENS 6ES7 223-1BL32-0XB0 EM 223 expansion module?

A: You can install the EM 223 expansion module by securely mounting it on a DIN rail and connecting it to your SIMATIC S7-200 CPU. Power (24V DC) and communication (via RS485) interfaces should be properly wired according to the installation guide for reliable operation.

Q: What are the typical applications for this EM 223 module?

A: The EM 223 is commonly used in industrial automation, machine control, and process automation. It is designed to provide scalable digital input and relay output capabilities within the manufacturing, packaging, and control system domains.

Q: When should I consider adding this expansion module to my S7-200 PLC setup?

A: You should add the EM 223 when your current S7-200 CPU module needs additional digital inputs or relay outputs beyond its onboard capacity. This module supports system growth for projects with expanding requirements.

Q: Where can the EM 223 module be installed for optimal performance?

A: The module should be installed in a control panel or enclosure with adequate ventilation, away from direct exposure to dust, moisture, and temperature extremes. Its compact size lets it fit easily alongside other DIN rail-mounted equipment.

Q: What is the process for configuring the digital inputs and outputs?

A: Configuration is managed through the S7-200 programming software, where you can assign functions to each input and output. The relays support both DC and AC loads, and digital inputs can be programmed for standard operations or high-speed counting, depending on system requirements.

Q: How does this module benefit industrial automation projects?

A: The EM 223 enhances automation flexibility by providing extra I/O, supporting digital and relay operations. Its integrated communication port allows for efficient remote management and data exchange, facilitating easier expansion and improved process control.

Q: What types of sensors and devices can be connected to the EM 223?

A: You can connect a wide range of digital sensors and actuators directly to the module's inputs and relay outputs. With appropriate additional modules, it also supports analog sensors, offering versatile compatibility for various automation tasks.
