SIEMENS 6AV2 124-0JC01-0AX0 HMI

Get a Price/Quote
MOQ : 1 Piece

SIEMENS 6AV2 124-0JC01-0AX0 HMI Specification

  • Features
  • Touch screen, multi-language, web server support, data logging, user administration, alarms
  • Application
  • Industrial Automation, Process Control
  • Frequency
  • 50/60 Hz (not applicable; DC powered)
  • Phase
  • Not applicable (DC powered)
  • Connectivity Type
  • Ethernet, Profibus, USB 2.0, RS-485
  • Automation Grade
  • Automatic
  • Processor Type
  • ARM Cortex-A8, 1GHz
  • Screen Size
  • 7-inch TFT color display
  • Cable Length
  • Depends on installation, not fixed
  • Remote Control
  • Yes
  • Mounting Type
  • Panel Mount
  • IP Rating
  • IP65 (front), IP20 (rear)
  • Control Type
  • Touch
  • Weight
  • Approx. 1.1 kg
  • Material
  • Plastic and Metal (Front: Polycarbonate; Rear: Aluminum)
  • Power
  • 24 V DC, max. 9 W
  • Temperature
  • Operating: 0C to 50C; Storage: -20C to 60C
  • Voltage
  • 24V DC (rated)
  • Screen Resolution
  • 800 x 480 pixels
  • Display Colors
  • 16 million colors
  • Flash Memory
  • 2 GB
  • Memory RAM
  • 2 GB
  • Interface Ports
  • 2x Ethernet (RJ45), 2x USB, 1x SD card slot
  • Product Type
  • SIMATIC HMI Unified Comfort Panel
  • Front Material
  • Polycarbonate
  • Dimensions
  • Height 158 mm x Width 238 mm x Depth 51 mm
  • Operating System
  • SIMATIC WinCC (TIA Portal) compatible
  • Relative Humidity
  • 10% to 90%, non-condensing
  • Touch Technology
  • Analog resistive
  • Model
  • 6AV2 124-0JC01-0AX0
  • Cooling
  • Fanless design
  • Backlight Lifespan
  • minimum 50,000 hours at 25C


SIEMENS 6AV2 124-0JC01-0AX0 HMI Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 100 Pieces Per Month
  • Delivery Time
  • 7 Days


About SIEMENS 6AV2 124-0JC01-0AX0 HMI

SIEMENS 6AV2 124-0JC01-0AX0 HMI


Siemens6AV2124-0JC01-0AX0isahigh-performancehuman-machineinterface(HMI)paneldesignedforindustrialautomationapplications.Keyfeaturesinclude:




Advanced Touchscreen Performance

Enjoy unparalleled control with the SIEMENS 6AV2 124-0JC01-0AX0, offering a vibrant 7-inch TFT color display and responsive analog resistive touch functionality. Its multi-language interface and user-friendly design empower operators across industrial environments, while the panel's precise touch technology ensures effortless navigation and command input.


Connectivity and Integration

This HMI panel is equipped with 2x Ethernet (RJ45), 2x USB, and an SD card slot for flexible integration with industrial networks and devices. It is compatible with SIMATIC WinCC (TIA Portal), facilitating seamless configuration, data exchange, and remote management to streamline automation processes.


Built for Industrial Reliability

With an IP65-rated front, fanless cooling, and robust polycarbonate and aluminum construction, this panel withstands harsh industrial conditions. The 50,000-hour backlight lifespan and operation across wide temperature and humidity ranges make it ideal for continuous use in critical process control applications.

FAQ's of SIEMENS 6AV2 124-0JC01-0AX0 HMI:


Q: How do I set up the SIEMENS 6AV2 124-0JC01-0AX0 HMI for my automation project?

A: Begin by mounting the panel into your control cabinet using panel mount installation. Connect the required power input (24V DC, max. 9W), network interfaces (Ethernet, Profibus, RS-485), and peripheral devices via USB or SD card slot. Configure the device using the SIMATIC WinCC (TIA Portal) software for seamless integration into your automation network.

Q: What are the main benefits of using this HMI in industrial automation?

A: The panel delivers reliable process visualization, touch-based control, remote monitoring, and comprehensive data logging capabilities. Its robust design, multi-language support, and wide connectivity options enhance productivity and enable flexible deployment in diverse industrial settings.

Q: When should I use the remote control feature of this panel?

A: Remote control is ideal when operators or engineers need to monitor, troubleshoot, or update the system without direct physical access. Simply utilize the network interfaces and web server support to securely access the HMI from a remote location within your facility's network.

Q: Where can this HMI panel be effectively installed?

A: Designed primarily for panel-mount installation, this HMI is perfect for indoor industrial environments such as factory floors, control rooms, and process automation panels. The IP65-rated front ensures protection against dust and splashing water, making it suitable even for harsh production areas.

Q: What process does the panel follow to ensure data reliability and security?

A: The HMI uses robust data logging, user administration, and alarm features, ensuring consistent recording and secure management of process information. Its compatibility with SIMATIC WinCC (TIA Portal) further enhances system integrity and operator access control.

Q: How do I maintain optimal operation and longevity of the display?

A: Keep the front surface clean and avoid exposure to extreme dust or moisture beyond rated specifications. Operate within 0C to 50C ambient temperature, and ensure non-condensing humidity levels between 10% and 90%. The backlight is rated for at least 50,000 hours at 25C, ensuring prolonged clarity and display performance.
