SCHNEIDER TSXDEY16A5 PLC
SCHNEIDER TSXDEY16A5 PLC
SCHNEIDER TSXDEY16A5 PLC
SCHNEIDER TSXDEY16A5 PLC
SCHNEIDER TSXDEY16A5 PLC
SCHNEIDER TSXDEY16A5 PLC
images Send Inquiry
Request To Call Back

SCHNEIDER TSXDEY16A5 PLC

Get a Price/Quote
MOQ : 1 Piece

SCHNEIDER TSXDEY16A5 PLC Specification

  • Connectivity Type
  • Backplane Bus
  • Weight
  • Approx. 200 g
  • Features
  • 16 Point Digital Output, Removable Terminal Block, LED Status Indicators
  • Load Capacity
  • 0.5 A per channel
  • Mounting Type
  • Rack Mount/DIN Rail Mount
  • Cable Length
  • Dependent on installation; Not specified
  • Processor Type
  • Not Applicable (I/O Module)
  • IP Rating
  • IP20
  • Control Type
  • Digital Output
  • Application
  • Industrial Automation, Factory Control
  • Remote Control
  • Yes
  • Phase
  • Single Phase
  • Frequency
  • 50/60 Hz
  • Automation Grade
  • Automatic
  • Material
  • Plastic, Metal
  • Power
  • 3 W (typical)
  • Temperature
  • 0C to 60C (operating)
  • Voltage
  • 24 V DC
  • Number of Outputs
  • 16 Channels
  • Response Time
  • 0.5 ms (on/off)
  • Channel Type
  • Transistor (Solid State)
  • Storage Temperature
  • -25C to 70C
  • Output Type
  • Source (Positive Logic)
  • Dimensions
  • 125 x 32 x 123 mm (W x D x H)
  • Compatible PLCs
  • TSX Micro / Premium Series
  • Relative Humidity
  • 5% to 95% (non-condensing)
  • Module Reference
  • TSXDEY16A5



About SCHNEIDER TSXDEY16A5 PLC

SCHNEIDER TSXDEY16A5 PLC


The TSXDEY16A5is a discrete input modulefrom the Modicon Premiumautomation platform, designed for 16 capacitive isolated digital inputsIt operates with a voltage of 220 V ACand has a current consumption of 15 mAThe module is compatible with 2/3 wire proximity sensorsand is rated for EN/IEC 61131-2 type 2It features a screw terminal block connectionand is suitable for use in harsh industrial environments, with an ambient temperature range of +32...+140F / 0...+60 Cand a humidity level of 10-95%without condensation.



High-Efficiency Digital Output for Industrial Control

The TSXDEY16A5 module provides 16 individual digital output channels utilizing solid-state transistor technology, ensuring swift switching and precise control for automation systems. Its source (positive logic) configuration is optimal for consistent and reliable factory operations, making it an exceptional choice for modern industrial applications.


Simple Integration and Flexible Mounting

Supporting both rack and DIN rail mounting, this module is designed for seamless installation in various control cabinets. The removable terminal block simplifies wiring and maintenance, while LED status indicators allow for quick channel diagnostics and monitoring during operation.


Reliable Operation in Demanding Environments

Engineered with industrial-grade components, the TSXDEY16A5 withstands a wide range of temperature and humidity conditions. Its durable plastic and metal construction, combined with a typical 3 W power consumption and a 24 V DC rating, make it a dependable solution for critical automation processes.

FAQ's of SCHNEIDER TSXDEY16A5 PLC:


Q: How do I connect the TSXDEY16A5 module to my PLC system?

A: The TSXDEY16A5 is compatible with TSX Micro and Premium series PLCs. Simply install the module onto the backplane bus of your rack or DIN rail-mounted system and connect your output devices to the removable terminal block.

Q: What are the advantages of using a transistor (solid state) output in this module?

A: Transistor outputs provide fast switching times (0.5 ms on/off), long operational life, and low maintenance requirements due to the absence of mechanical contacts-making them ideal for high-speed industrial automation.

Q: When should I use the TSXDEY16A5 module in my automation project?

A: The TSXDEY16A5 is best used when you require up to 16 independent digital outputs (source type) with reliable performance and quick response times, particularly in industrial automation, factory control, and other critical digital signaling tasks.

Q: Where can the TSXDEY16A5 be installed for optimal performance?

A: Install the module in a well-ventilated control cabinet meeting the environmental specifications (0C to 60C, 5%-95% non-condensing humidity), using either rack mount or DIN rail mount depending on your setup.

Q: What process steps are required to maintain the TSXDEY16A5?

A: Routine inspection of wiring and terminal blocks, cleaning the surface to prevent dust accumulation, and monitoring the status LEDs for error indication will help maximize the lifespan and reliability of the module.

Q: How does the LED status indicator benefit users?

A: LEDs on the TSXDEY16A5 give real-time visual feedback for each output channel, allowing for quick identification of channel status and rapid troubleshooting during operation or maintenance tasks.
