SCHNEIDER 140CPS11100 PLC

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER 140CPS11100 PLC Specification

Phase
Single Phase

Connectivity Type
Rack mounted backplane connection

Mounting Type
Rack/DIN Rail mount

IP Rating
IP20

Remote Control
Yes

Weight
0.88 kg

Control Type
Programmable Logic Controller

Processor Type
Not applicable (Power Supply Module)

Automation Grade
Automatic

Frequency
50/60 Hz (for connected modules)

Application
Used for powering and controlling Modicon Quantum PLC racks and modules

Features
Hot swap capability, Status indicators, Electronic protection against overload and short circuit

Load Capacity
Power Supply output up to 11A at 5V DC (Rack backplane)

Material
Plastic and Metal Housing

Power
No internal power supply (uses external 24/48/60/100/115/125/220 V DC power supplies)

Temperature
0C to 60C (operating); -40C to 85C (storage)

Voltage
Input voltage range: 24/48/60/100/115/125/220 V DC (depending on model configuration)

Cooling Method
Natural air convection

Module Type
Power Supply Module

Storage Humidity
5% to 95% (non-condensing)

Dimensions (W x H x D)
63 mm x 298 mm x 167 mm

Status Indicators
Green LED for RUN, Red LED for FAULT

Redundancy
Supports redundant configuration with compatible modules

Operating Altitude
Up to 2000 m

Model Number
140CPS11100

Backplane Current Supply
11 A

Product Series
Modicon Quantum

Output Current
11 A at 5 V DC

About SCHNEIDER 140CPS11100 PLC

SCHNEIDER 140CPS11100 PLC

The Schneider 140CPS11100 is a high-performance power supply module used in Schneider Electric Quantum programmable logic controllers (PLCs). It is designed to provide reliable and stable power to the PLC system, ensuring smooth and efficient operation.

Reliable Power for Quantum Automation

Engineered for Modicon Quantum PLC racks, the 140CPS11100 Power Supply Module offers consistent, high-output performance essential for complex automated systems. Supporting up to 11A at 5V DC, its advanced protection mechanisms and redundant configuration support maximize uptime in mission-critical industries, from manufacturing to processing.

Flexible Installation & Maintenance

With versatile mounting options and hot-swap capability, maintaining or upgrading your Quantum PLC system is streamlined. The unit's lightweight construction, combined with IP20 protection and natural convection cooling, ensures safe, easy integration even in challenging industrial environments.

Comprehensive System Monitoring

Status indicators, including a green RUN LED and red FAULT LED, provide immediate operational feedback. These intuitive visuals help staff quickly identify and resolve issues, boosting productivity, and safeguarding valuable automation equipment against unexpected downtime.

FAQ's of SCHNEIDER 140CPS11100 PLC:

Q: How is the SCHNEIDER 140CPS11100 power supply module installed in a Modicon Quantum PLC system?

A: The 140CPS11100 power supply module is designed for easy rack or DIN rail mounting within a Modicon Quantum PLC system. Simply insert the module into the backplane slot and secure it in place according to manufacturer instructions to establish backplane connectivity.

Q: What voltage input options does the 140CPS11100 module support?

A: This module accepts a wide range of DC input voltages, including 24, 48, 60, 100, 115, 125, and 220 V DC. The compatible voltage depends on the specific model configuration ordered, allowing flexible integration into various industrial setups.

Q: When should redundant power supply configurations be considered with this module?

A: Redundant configurations are recommended for applications requiring high availability and minimal downtime. The 140CPS11100 can be paired with compatible redundant modules, ensuring continuous operation if one power supply fails.

Q: Where can the 140CPS11100 power supply be used considering environmental conditions?

A: The module operates optimally between 0C and 60C (operating) and can be stored at temperatures from -40C to 85C. It accommodates humidity from 5% to 95% (non-condensing) and functions at altitudes up to 2000 meters, making it suitable for a wide range of industrial environments.

Q: What benefits does the 140CPS11100 offer in terms of system protection?

A: It features electronic protection against overload and short circuit, along with status LEDs for RUN and FAULT. These features enhance system safety, allowing for easier troubleshooting and minimizing risk to connected automation equipment.

Q: How do the status indicators assist in module operation?

A: The green RUN LED signals normal operation, while the red FAULT LED alerts users to issues. These indicators facilitate quick diagnostics, helping operators promptly address system faults and reduce downtime.

Q: What usage scenarios make the 140CPS11100 ideal for automation?

A: Designed for automatic control systems, this power supply is particularly suitable for powering and managing Modicon Quantum PLC racks and modules in processing, manufacturing, and infrastructure automation, where reliable, efficient power is crucial.
