RISH MASTER 3480 MULTI-FUNCTION METER

Get a Price/Quote

MOQ : 1 Piece

RISH MASTER 3480 MULTI-FUNCTION METER Specification

Application
Energy Monitoring and Measurement

Mounting Type
Panel Mount

Phase
Three Phase/Single Phase

Remote Control
Yes

Cable Length
User defined (not supplied)

Connectivity Type
RS-485 (Modbus RTU)

Control Type
Digital

Load Capacity
For LV and MV applications

Automation Grade
Automatic

Sensor Type
True RMS measurement

Processor Type
Microcontroller Based

IP Rating
IP54 (front panel)

Screen Size
96 x 96 mm (panel size)

Weight
Approx. 480 g

Frequency
45Hz - 65Hz

Material
Plastic Body, Flame Retardant Material

Power
Auxiliary supply: 40-300V AC/DC

Temperature
Operating: -10C to +55C

Voltage
Direct: 10-600V AC (Ph-N), 10-1000V AC (Ph-Ph)

Measured Parameters
Voltage, Current, Active/Reactive/Apparent Power, Power Factor, Frequency, Energy

Dimension
96 x 96 x 52 mm

Model
Rish Master 3480

Data Output
RS-485 Serial Port (Modbus RTU)

Overload Withstand
Voltage: 2 x rated, Current: 2 x rated

Accuracy
Class 0.5S for Energy, Class 0.2 for Voltage/Current

Consumption
<5VA

Display
Bright backlit LCD display, 4 Lines

RISH MASTER 3480 MULTI-FUNCTION METER Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About RISH MASTER 3480 MULTI-FUNCTION METER

RISH MASTER 3480 MULTI-FUNCTION METER

RISH Master 3480 measures important electrical parameters in 3 phase and single phase Network & replaces the multiple analog panel meters. It measures electrical parameters like AC current, Voltage, frequency, active energy import & active energy export, Current Demand, kW Demand, kVA Demand and Max Current Demand, Max kW Demand and Max kVADemand. The instrument has optional output as one pulse output or two pulse output for energy measurement.

Comprehensive Monitoring

Equipped to measure crucial parameters-including voltage, current, active/reactive/apparent power, energy, frequency, and power factor-the RISH MASTER 3480 supplies users with actionable insights for energy efficiency and system health. Its precise monitoring is essential for industrial, commercial, and utility environments.

User-Friendly Design

The panel-mounted, 96 x 96 mm meter features an intuitive LCD display with backlighting, making readings clearly visible in diverse lighting conditions. Its compact, lightweight structure and IP54-rated front panel enable robust placement even in demanding operational settings.

Advanced Communication

With RS-485 serial connectivity and Modbus RTU protocol, the RISH MASTER 3480 integrates seamlessly into digital control and monitoring systems. This facilitates remote data acquisition and real-time tracking, optimizing facility management and energy usage.

FAQ's of RISH MASTER 3480 MULTI-FUNCTION METER:

Q: How do I install the RISH MASTER 3480 Multi-Function Meter?

A: The RISH MASTER 3480 is designed for easy panel mounting with a 96 x 96 mm cutout. Ensure wiring aligns with the provided installation guidelines, paying attention to phase connections and auxiliary power supply (40-300V AC/DC). Professional installation is recommended for safety and accuracy.

Q: What parameters does this meter measure and display?

A: This meter displays voltage, current, active power, reactive power, apparent power, energy (kWh), power factor, and frequency on a four-line, bright backlit LCD. It supports measurements for both single-phase and three-phase systems, making it versatile for various monitoring needs.

Q: When should I use the RS-485 (Modbus RTU) communication port?

A: The RS-485 (Modbus RTU) data output is ideal when you need remote monitoring, integration with SCADA or building management systems, or automated data collection for analytical or reporting purposes in energy management.

Q: Where can the RISH MASTER 3480 be used?

A: This meter is suitable for energy monitoring in industrial, commercial, and utility environments-particularly where accurate multi-parameter measurement for low and medium voltage systems is crucial. Its robust construction and IP54-rated panel front allow usage in harsh conditions.

Q: What are the main benefits of using the RISH MASTER 3480?

A: Key benefits include high measurement accuracy, real-time multi-parameter display, digital communication capabilities for seamless integration, and a user-friendly interface. These features support effective energy management, cost savings, and improved operational reliability.

Q: How accurate is the meter for energy and electrical parameter measurement?

A: The RISH MASTER 3480 offers Class 0.5S accuracy for energy readings and Class 0.2 for voltage and current, ensuring highly precise monitoring that meets industry standards for critical applications.

Q: What type of sensors are used and why is this important?

A: It employs true RMS measurement sensors, which deliver accurate readings regardless of waveform distortions. This is especially important in environments with non-linear loads, helping maintain reliable monitoring and system awareness.
