MTL MA15/D/1/SI POWER PROTECTED

Get a Price/Quote

MOQ : 1 Piece

MTL MA15/D/1/SI POWER PROTECTED Specification

Mounting Type
DIN Rail

Cable Length
Not Included

Application
Instrumentation, Process Control Systems, DCS, Telemetry, PLC I/O, Electronic Equipment

Frequency
50/60 Hz (Signal Compatibility)

Control Type
Surge Protection Device

Phase
Single

IP Rating
IP20

Features
Low leakage current, Fast response time, High surge current capacity, Maintenance free, Compact Design

Automation Grade
Industrial

Weight
Approx. 55 g

Connectivity Type
DIN Rail Mounted, 2-Wire/3-Wire Applications

Material
High Quality Metal Alloy Casing

Power
Surge Protected (no direct power consumption)

Temperature
-40C to +85C Operating Range

Voltage
15V (Nominal Clamping Voltage)

Let Through Voltage
Less than 40V

Connection
Screw Terminals, up to 4mm2 Cable

Dimensions
94 mm x 12.5 mm x 68 mm (H x W x D)

Compliance
UL, IEC, CSA, ATEX (when installed as per guidelines)

Product Code
MA15/D/1/SI

Surge Current Capacity
20 kA (8/20s) per mode

Enclosure Material
Thermoplastic UL94-V0

Response Time
<10 ns

Colour
Blue

MTL MA15/D/1/SI POWER PROTECTED Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About MTL MA15/D/1/SI POWER PROTECTED

MTL MA15/D/1/SI POWER PROTECTED

MTL MA15 surge protection devices protects electronic equipment and computer networks against the effects of ?noise pollution? induced in mains power supplies. MA15/D/1/SI has a working AC voltage of 120V, or a working DC voltage of 140V. Spec Sheet Manual

Advanced Surge Protection for Sensitive Electronics

Engineered for high-performance environments, the MTL MA15/D/1/SI offers exceptional surge protection for critical equipment like instrumentation, DCS, PLC I/O, and telecommunication devices. Its fast-reacting circuitry minimizes equipment downtime and extends lifespan by isolating damaging voltage spikes and transients.

Rugged and Reliable Build Quality

Constructed from quality thermoplastic (UL94-V0 rated) and encased in high-grade metal alloy, the unit combines a lightweight profile with industrial durability. It's designed for simple integration into existing automation systems via DIN rail mounting, making it suitable for distributors, exporters, manufacturers, and end users in demanding industries.

FAQ's of MTL MA15/D/1/SI POWER PROTECTED:

Q: How is the MTL MA15/D/1/SI POWER PROTECTED device installed?

A: The device is designed for DIN rail mounting and uses screw terminals that accommodate cables up to 4mm2, ensuring quick and secure installation in control cabinets or enclosures.

Q: What types of equipment can benefit from using this surge protection device?

A: It is ideal for safeguarding sensitive components in instrumentation, process control systems, distributed control systems (DCS), telemetry, PLC I/O, and other electronic equipment in industrial settings.

Q: When should I consider integrating this device into my automation system?

A: Install the MA15/D/1/SI whenever you need to protect valuable electronic systems from transient surges, particularly in environments prone to electrical disturbances or lightning strikes.

Q: Where can the device be safely used considering environmental conditions?

A: With an operating temperature range from -40C to +85C and robust IP20 protection, it is suitable for a wide range of industrial settings, but should be installed inside enclosures to prevent direct exposure to harsh elements.

Q: What is the process for connecting the MTL MA15/D/1/SI to an existing system?

A: Simply mount the device on a DIN rail, then connect input and output wires via the screw terminals. The unit supports both 2-wire and 3-wire configurations for flexible integration.

Q: How does this device protect my equipment from surges?

A: It reacts in less than 10 nanoseconds to voltage transients, limiting let-through voltage to below 40V and handling up to 20 kA surge per mode, thereby preventing equipment damage and improving system reliability.

Q: What are the main benefits of using the MA15/D/1/SI surge protector?

A: The device provides advanced, maintenance-free surge protection with fast response time, high surge capacity, and low leakage current. Its compact form factor makes it easy to install without sacrificing valuable cabinet space.
