MITSUBISHI E1061 (TYPE:-06705) HMI (CORNER BROKEN)

Get a Price/Quote
MOQ : 1 Piece

MITSUBISHI E1061 (TYPE:-06705) HMI (CORNER BROKEN) Specification

  • Control Type
  • Touchscreen
  • Automation Grade
  • Automatic
  • Weight
  • Approx. 650 grams
  • Connectivity Type
  • RS232, RS422, RS485 Ports
  • Features
  • Touchscreen, Programmable Panel, Graphic Display, Multi-language, Alarm Handling
  • IP Rating
  • IP65 (Front)
  • Screen Size
  • 5.7 inch
  • Frequency
  • 50/60 Hz
  • Processor Type
  • Proprietary Mitsubishi HMI Processor
  • Phase
  • Single Phase
  • Application
  • Industrial Automation, PLC Control Panel
  • Mounting Type
  • Panel Mount
  • Material
  • Plastic, Electronic Components
  • Power
  • 24V DC
  • Temperature
  • 0C to 50C (Operating)
  • Voltage
  • 24V DC



About MITSUBISHI E1061 (TYPE:-06705) HMI (CORNER BROKEN)

MITSUBISHI E1061 (TYPE:-06705) HMI CORNER BROKEN


E1061 Module Type: Operator Interface Panel Weight: 1.92lb (0.87kg) Panel Size: 5.7 inch Pixels: 320 X 240 Pixels Storage: 12MB



Robust Touchscreen Interface for Industrial Automation

The E1061 HMIs analog resistive touchscreen and graphic display enhance operator interaction with automated systems. Its multi-language capabilities and alarm handling features provide convenience and reliability for diverse industrial applications. The compact design and panel mount make it suitable for control panels within PLC-driven environments.


Built to Withstand Tough Conditions

Protected by an IP65-rated front and an operating temperature range of 0C to 50C, the E1061 is engineered to endure demanding industrial settings. Its durable plastic build and CCFL backlight ensure longevity even where humidity reaches up to 90% RH (non-condensing), making it a solid choice for manufacturing facilities and automation hubs.

FAQs of MITSUBISHI E1061 (TYPE:-06705) HMI (CORNER BROKEN):


Q: How does the damaged corner affect the performance of the MITSUBISHI E1061 HMI panel?

A: While the corner is physically broken, the units core functionalitytouchscreen control, graphic display, connectivity, and automation capabilitiesremains intact. Users should verify mounting compatibility and ensure the break doesnt compromise sealing or interfere with connections.

Q: What are the main benefits of using the E1061 HMI in an industrial PLC control panel?

A: The E1061 offers intuitive touch control, multi-language support, alarm management, and high connectivity (RS232, RS422, RS485). These features streamline operations, improve process oversight, and suit diverse automation requirements, optimizing productivity in industrial environments.

Q: Where is the MITSUBISHI E1061 HMI typically installed and used?

A: This panel is commonly panel-mounted in industrial automation settings such as manufacturing plants, factories, and other operations utilizing PLC control systems. Its IP65-rated front and robust design make it ideal for harsh and demanding environments.

Q: What is the process for integrating the E1061 HMI with existing PLC systems?

A: Connecting the E1061 to a PLC involves wiring its RS232, RS422, or RS485 communication ports to compatible PLC hardware. Configuration is then carried out using Mitsubishis proprietary software, allowing for display setup, language selection, and alarm programming.

Q: Which languages are supported by the E1061 HMI panel?

A: The E1061 supports multiple languages, enabling operators from various linguistic backgrounds to navigate and control industrial processes easily, enhancing user accessibility and reducing training time.

Q: What usage guidelines should be followed for storage and operation of the E1061?

A: Store the HMI between -20C and 60C in dry, non-condensing conditions. During operation, ensure the environment stays within 0C to 50C and between 10% to 90% relative humidity to prevent damage and preserve performance.
