DELTA DOP-107WV HMI

Get a Price/Quote

MOQ : 1 Piece

DELTA DOP-107WV HMI Specification

Control Type
Touch Screen HMI

Processor Type
32-bit RISC CPU

Weight
Approx. 600g

Mounting Type
Panel Mount

IP Rating
IP65 (Front Panel)

Screen Size
7 Inch (800 x 480 pixels) TFT LCD

Features
Multi-language support, Data Logging, Recipe Management

Connectivity Type
Ethernet, Serial Port (RS232/RS485), USB

Cable Length
Depends on installation; cables not included

Frequency
50/60 Hz

Automation Grade
Automatic

Phase
Single Phase

Application
Industrial Automation, Machine Control

Material
Plastic and Metal Housing

Power
5.0 W (typ.), 6.0 W (max.)

Temperature
Operating: 0C to 50C, Storage: -20C to 60C

Voltage
24 V DC (10.8 to 28.8 V DC)

Operating Humidity
10% to 90% RH (non-condensing)

Display Color
65,536 Colors

Memory
128 MB Flash, 128 MB RAM

Cutout Size
192 mm x 138 mm

Backlight
LED, 50,000 hrs (typ.)

Dimensions
200.4 mm x 146.5 mm x 34 mm (W x H x D)

Communication Ports
1 x Ethernet (RJ45), 2 x COM (RS-232/RS-422/RS-485), 1 x Mini USB, 1 x USB Host

Touch Panel
4-wire Resistive

Audio Output
Buzzer

About DELTA DOP-107WV HMI

DELTA DOP-107WV HMI

The Delta Electronics 7 inches TFT LCD advanced narrow frame type HMI adopts a wide screen and narrow frame design. It supports Ethernet communication & multilingual inputs. The multimedia type DOP-112/115 offers multimedia functions to meet different applications.

Versatile Connectivity for Industrial Systems

The DOP-107WV is equipped with one Ethernet port, two serial ports, a mini USB, and a USB host, supporting broad integration possibilities. Whether upgrading legacy equipment or deploying new installations, its robust port selection ensures smooth communication with PLCs, sensors, and controllers.

Intuitive 7-Inch Touchscreen for User-Friendly Control

Enjoy clear operation and vivid visualization with the 7-inch TFT LCD, offering 800 x 480 pixel resolution and 65,536 display colors. The responsive 4-wire resistive touch panel simplifies navigation, recipe management, and data logging for machine operators.

Reliable Performance in Demanding Environments

This HMI's IP65-rated front panel, broad operating temperature range (0C to 50C), and durable plastic and metal housing ensure consistent operation in tough industrial settings. Multi-language support and audio buzzer further enhance usability on busy shop floors.

FAQ's of DELTA DOP-107WV HMI:

Q: How is the DELTA DOP-107WV HMI typically installed?

A: The DOP-107WV is designed for panel mounting. Simply cut a hole in your control panel with dimensions 192 mm x 138 mm, insert the device, and secure it in place. Ensure that the environment meets the recommended IP65 standards at the front panel for optimal protection.

Q: What communication options does the HMI offer for system integration?

A: This HMI provides multiple connectivity options, including one Ethernet (RJ45) port, two serial ports (RS-232/RS-422/RS-485), a mini USB port, and a USB host. These interfaces enable seamless connection to PLCs, sensors, and other industrial equipment.

Q: Where can the DOP-107WV be used within industrial automation?

A: It is ideal for machine control, process monitoring, and various industrial automation applications where reliable human-machine interaction is essential-such as manufacturing, processing plants, and machinery panels.

Q: What are the main benefits of using this HMI in an automated system?

A: Key benefits include user-friendly touch operation, data logging, recipe management, multi-language support, durable IP65 front panel protection, and versatile connectivity. These features streamline machine setup, reduce errors, and enhance operator productivity.

Q: When should the HMI be replaced or serviced?

A: The LED backlight has a typical lifespan of 50,000 hours. Routine inspections are advised, especially in high-use environments. Replace or service the HMI if the display dims, touch responsiveness decreases, or the device no longer communicates reliably.

Q: What is the recommended power supply and operating conditions for this unit?

A: Supply the device with 24 V DC (acceptable range: 10.8 to 28.8 V DC), ensuring total power consumption stays between 5.0 W (typical) and 6.0 W (maximum). Operate it within 0C to 50C and maintain humidity between 10% and 90% RH (non-condensing).

Q: How does the multi-language capability improve user experience?

A: Multi-language support allows operators from varied backgrounds to interact with the interface in their preferred language, reducing the learning curve and minimizing operational errors in diverse industrial teams.
