DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER

Price 1 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER Specification

  • Cable Length
  • Up to 10 meters (with recommended cable type for display unit)
  • Weight
  • Approx. 1.2 kg
  • Screen Size
  • 3.5 inch color TFT display (320×240 pixels)
  • Sensor Type
  • Support for analog and digital sensors
  • Processor Type
  • 32-bit ARM Cortex microprocessor
  • Speed Range
  • Engine speed measurement up to 6000 RPM
  • Load Capacity
  • Rated for up to 20 paralleling gensets
  • Drive Type
  • Electronic governor and actuator compatible
  • Application
  • Advanced controlling and synchronisation of gensets, protection and monitoring
  • IP Rating
  • IP65 (front), IP20 (rear)
  • Phase
  • Three phase or Single phase
  • Remote Control
  • Yes
  • Automation Grade
  • Automatic
  • Control Type
  • Microprocessor based digital control
  • Mounting Type
  • Flush panel mounting
  • Frequency
  • 50/60 Hz (auto detection)
  • Features
  • Auto mains failure, load sharing, remote monitoring, easy commissioning, advanced protection features
  • Connectivity Type
  • Ethernet (Modbus TCP/IP), USB, CAN bus (CANopen & J1939), RS485 (Modbus RTU)
  • Material
  • Polycarbonate, ABS plastic front with metal rear panel
  • Power
  • 24 V DC (18 to 36 V DC range)
  • Temperature
  • Operating: -25°C to +70°C
  • Voltage
  • Fuel, auxiliary and power supply: 24 V DC, Digital inputs: 24 V DC, Relay outputs: 250 V AC/30 V DC
  • Event Log
  • 250+ event records with real time stamp
  • Operating Humidity
  • Up to 95% RH non-condensing
  • Data Logging
  • Integrated high-performance logger with user data export
  • Battery Back-up
  • Real time clock with battery backup
  • Protection Features
  • Overload, short circuit, under/over voltage, under/over frequency, and phase failure protection
  • Alarm Outputs
  • Independently programmable relay outputs
  • Display Resolution
  • 320 x 240 pixels TFT QVGA
  • Firmware Upgrade
  • Upgradable via USB stick or Ethernet
  • Dimensions
  • 144 x 144 x 70 mm (H x W x D)
  • Input/Output Expansion
  • Expandable I/O via CAN bus modules
  • Language Options
  • Multi-language support (English, Spanish, French, etc.)


DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 100 Pieces Per Month
  • Delivery Time
  • 7 Days


About DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER

DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER


AGC 150 contains all necessary 3-phase measuring circuits, and all values and alarms are presented on the sun proof LCD display. Automatic, Multiple Diesel generator changeover and controller enables energy management. It can handle even solar with 2 DGs or other input power sources.



Seamless Integration and Connectivity

The ML150-AGC150 supports multiple connectivity protocolsincluding Ethernet (Modbus TCP/IP), CAN bus (CANopen & J1939), USB, and RS485enabling straightforward interfacing with monitoring systems or SCADA. With firmware upgrades via Ethernet or USB and remote control possibilities, it provides flexibility for modern genset applications.


Enhanced Protection and Monitoring

This controller provides comprehensive protection mechanisms against overload, short circuit, voltage and frequency irregularities, and phase failure. Its event and data logging functions offer over 250 event records, each stamped in real time, aiding in diagnostics and compliance documentation for critical operations.


Advanced Features for Reliable Operation

The ML150-AGC150 features user-customizable alarm outputs, a battery-backed real-time clock, multi-language support, and flush panel mounting. Its durable construction (polycarbonate/ABS front, metal rear) and wide operating temperature and humidity range ensure reliability in harsh industrial environments.

FAQs of DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER:


Q: How can the DEIF ML150-AGC150 controller be integrated with existing generator systems?

A: The ML150-AGC150 can be easily integrated with new or existing generator sets using flush panel mounting. It supports three-phase and single-phase configurations and offers multiple I/O expansions via CAN bus modules to accommodate a wide variety of monitoring and control requirements.

Q: What types of protections does the controller offer for generator operation?

A: The controller includes built-in protection for overload, short circuit, under/over voltage, under/over frequency, and phase failure. These features safeguard both the genset and connected loads, ensuring operational reliability and equipment safety.

Q: When is it recommended to use the real-time data logging and event log features?

A: You should use the integrated data logger and 250+ event record capability during all periods of operation and maintenance. This aids in tracking historical performance, diagnosing issues quickly, and maintaining compliance with regulatory requirements.

Q: Where should the controller be installed for optimal performance?

A: For best results, the ML150-AGC150 should be mounted in a control panel using flush panel mounting. It is designed for front panel installation (IP65 rating) but should be placed in environments within -25C to +70C and up to 95% non-condensing humidity.

Q: What is the process for upgrading the controllers firmware?

A: Firmware upgrades can be performed conveniently via a USB stick or over Ethernet. Simply download the latest firmware from the manufacturers website, copy it to a compatible USB device, and follow the upgrade instructions in the user manual for a secure update.

Q: How does the controller benefit genset operations in industrial settings?

A: The ML150-AGC150 improves operational efficiency through automation (auto mains failure, load sharing), customizable alarm outputs, advanced diagnostics, and remote monitoring capabilities. Its robust construction and comprehensive features make it suitable for continuous, heavy-duty industrial use.
