DEIF AGC 150 ADVANCED GENSET CONTROLLER

Price 1 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

DEIF AGC 150 ADVANCED GENSET CONTROLLER Specification

  • Processor Type
  • Microcontroller, ARM core
  • Screen Size
  • 2.8 (approx.) colour display
  • Mounting Type
  • Flush and panel mounting
  • Remote Control
  • Yes
  • Weight
  • Approx. 0.8 kg
  • Control Type
  • Microprocessor based digital controller
  • Phase
  • Compatible for Single & Three Phase Gensets
  • Drive Type
  • Electrical drive interface
  • Load Capacity
  • Depends on Genset rating
  • Frequency
  • 50/60 Hz
  • Cable Length
  • As per installation requirement
  • Application
  • Advanced Genset Control, AMF (Auto Main Failure) & Synchronizing applications
  • IP Rating
  • IP65 (front)
  • Speed Range
  • Supports standard genset speed range
  • Features
  • Multiple Genset paralleling, auto and manual modes, event log, remote monitoring, advanced protection features.
  • Automation Grade
  • Automatic
  • Sensor Type
  • Supports CT, VT, temperature, and pressure sensors
  • Connectivity Type
  • RS485, CAN bus, Modbus, Ethernet (optional)
  • Material
  • High-grade industrial plastic & metal housing
  • Power
  • 12 to 24 V DC (typical)
  • Temperature
  • -30C to +70C operating range
  • Voltage
  • 8 to 36 V DC supply
  • Display Type
  • 128 x 64 graphical LCD, backlit
  • Dimension
  • 144 x 144 x 49 mm (H x W x D)
  • Digital Inputs
  • 8 configurable digital inputs
  • Power Consumption
  • <7 W (typical)
  • Battery Backup
  • Real-time clock with battery backup
  • Languages Supported
  • Multilingual interface
  • Relay Outputs
  • 6 configurable relay outputs
  • Alarm System
  • Configurable alarms and warnings
  • Compliance
  • CE, UL certified
  • Humidity
  • 95% RH non-condensing
  • Firmware Upgrades
  • Supported via USB/COM
  • Analog Inputs
  • 3 analog inputs (voltage, current, temp)
  • Event Log Capacity
  • 500 events


DEIF AGC 150 ADVANCED GENSET CONTROLLER Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 100 Pieces Per Month
  • Delivery Time
  • 7 Days


About DEIF AGC 150 ADVANCED GENSET CONTROLLER

DEIF AGC 150 ADVANCED GENSET CONTROLLER


The AGC 150 (Advanced Genset Controller) series is designed for OEMs and system designers and covers a wide range of power and engine control applications. It offers unmatched flexibility, high quality, and tried and tested reliability in a compact package. The AGC 150 series enables power management and (in most variants) synchronisation, giving OEMs and system designers a wide range of design options to choose from.



Comprehensive Generator Management

The AGC 150 controller provides automatic and manual control for single or multiple gensets, making it ideal for paralleling and synchronized operations. With multiple inputs and outputs, configurable alarms, and a robust microcontroller-based design, it streamlines complex power management tasks efficiently and dependably.


Advanced Protection and Monitoring Features

Equipped with a 500-event log, configurable alarms, and advanced sensor interfacing for CT, VT, temperature, and pressure, the controller ensures both operational safety and in-depth monitoring. Ethernet, CAN bus, Modbus, and RS485 support remote diagnostics and control, enhancing convenience and system reliability.

FAQ's of DEIF AGC 150 ADVANCED GENSET CONTROLLER:


Q: How can I upgrade the firmware on the DEIF AGC 150 Advanced Genset Controller?

A: Firmware upgrades are straightforward-connect to the controller via USB or a COM interface and use the manufacturer's update utility. Follow the provided instructions to ensure a secure and seamless process.

Q: What are the primary benefits of using the AGC 150 for genset applications?

A: The AGC 150 enables automatic and manual operation, multi-genset paralleling, advanced event logging, remote monitoring, and robust protection features. This ensures maximized uptime, simplified operation, and comprehensive control for both single and three-phase gensets.

Q: When should I use the event log feature, and what does it record?

A: Utilize the event log to track and analyze up to 500 recorded events, such as alarms, warnings, and operational states. This feature aids in troubleshooting, maintenance planning, and system performance optimization.

Q: Where can the AGC 150 controller be installed, considering its environmental tolerances?

A: The AGC 150 is suitable for installation in industrial environments, offering high durability with an IP65-rated front panel, support for temperatures from -30C to +70C, and resistance to 95% RH humidity (non-condensing). Flush and panel mounting options provide flexible integration.

Q: What process should be followed to connect external sensors to the controller?

A: Integrate compatible sensors-such as CT, VT, temperature, and pressure-via the configurable digital and analog inputs. Follow wiring diagrams and setup instructions in the manual to ensure accurate data acquisition and system protection.

Q: How does remote control and monitoring work with the AGC 150 controller?

A: Remote monitoring and control are possible through supported RS485, CAN bus, or optional Ethernet interfaces. By connecting to supervisory systems or SCADA via Modbus protocol, operators can manage and adjust settings from a distance, ensuring efficient oversight.

Q: What type of gensets and loads is the AGC 150 compatible with?

A: The controller supports both single-phase and three-phase gensets at 50/60 Hz, and its load capacity depends on the genset rating. It adapts to varying supply voltages (8-36 V DC) and supports typical genset speed ranges, making it suitable for a wide range of industrial power solutions.
