B&R X20 DO 9332 PLC

Get a Price/Quote

MOQ : 1 Piece

B&R X20 DO 9332 PLC Specification

IP Rating
IP20

Frequency
DC powered

Weight
Approx. 150 g

Connectivity Type
X20 system bus, removable terminal blocks

Phase
DC

Processor Type
Used with B&R CPUs (not onboard)

Cable Length
Up to 500 m (with proper wiring)

Remote Control
Yes

Application
Industrial automation systems, machine control

Automation Grade
Automatic

Load Capacity
0.5 A per channel

Control Type
Digital (Output)

Mounting Type
DIN rail mounting

Features
16 digital outputs, hot swappable, diagnostic LEDs, compact size

Material
Plastic and metal components

Power
24 VDC

Temperature
-25C to +60C (operation)

Voltage
24 VDC

Module Width
24 mm

Connection Type
Removable terminal block

System Compatibility
B&R X20 Series

Storage Temperature
-40C to +85C

Status Indication
LED per channel

Output Type
Digital, source (PNP)

Humidity Tolerance
5-95% non-condensing

Switching Capacity Per Output
0.5 A DC

Thermal Overload Protection
Yes

Short Circuit Protection
Yes, electronic

Number of Digital Outputs
16 channels

Output Voltage Range
19.2-30 VDC

B&R X20 DO 9332 PLC Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About B&R X20 DO 9332 PLC

B&R X20 DO 9332 PLC

TheB&RX20DO9332isahigh-performance32-channeldigitaloutputmoduledesignedfordemandingindustrialapplications.Eachchanneldelivers2Aoutputat24VDCmakingitsuitableforcontrollinglargerloadssuchascontactors,motorstarters,andhigh-powersolenoids.Themodulefeaturescomprehensiveprotection,includingshort-circuit,overload,andovertemperatureprotectiononallchannels,ensuringreliableoperationinharshenvironments.Additionally,itincorporatesindividualLEDstatusindicatorsforefficientdiagnosticsandmaintenance.

Versatile Digital Output for Automation

The X20 DO 9332 module offers 16 digital source (PNP) outputs tailored for B&R X20 Series systems, making it ideal for industrial control and automation. With reliable status indication through individual channel LEDs and robust protection features, it ensures efficient machine operations and minimized downtime.

Designed for Industrial Compatibility

Engineered with a compact 24 mm width and modular design, this PLC module supports easy DIN rail mounting as well as hot swapping without disrupting system operation. The removable terminal block simplifies installation, and its IP20 protection suits panel environments found in modern automation setups.

FAQ's of B&R X20 DO 9332 PLC:

Q: How do I install the B&R X20 DO 9332 PLC module?

A: The X20 DO 9332 module is installed on a DIN rail within your control panel. It uses a removable terminal block for straightforward wiring, and connects to the B&R X20 system bus, enabling quick integration with other X20 Series modules and B&R CPUs.

Q: What protection features are included in this module?

A: Each output channel features electronic short-circuit and thermal overload protection, ensuring safe operation and preventing damage from electrical faults or overheating during intensive use.

Q: When should I use the X20 DO 9332 in my automation system?

A: The module is ideal for applications requiring multiple digital outputs-such as industrial automation, machine control, and process systems-particularly where robust protection and diagnostic feedback are necessary.

Q: Where can the X20 DO 9332 be used regarding environmental conditions?

A: The module is suited for use in environments with operating temperatures from -25C to +60C, and can be stored between -40C and +85C. Its IP20 rating allows installation inside standard electrical control cabinets.

Q: What are the benefits of LED status indication on each channel?

A: Each output channel features an individual LED, offering real-time status feedback. This aids in rapid troubleshooting and monitoring, reducing system downtime and streamlining maintenance activities.

Q: How can I remotely control or monitor this output module?

A: The X20 DO 9332 supports remote monitoring and control via system integration with compatible B&R CPUs, utilizing the X20 system bus for communication and diagnostic data sharing throughout your automation network.

Q: What is the process for replacing the module during maintenance?

A: The module is hot swappable, allowing you to replace it without shutting down the entire system. Simply remove the terminal block, detach the module from the DIN rail, and install the new unit, minimizing operational interruptions.
