B&R X20 AI 4632-1 PLC

Get a Price/Quote

MOQ : 1 Piece

B&R X20 AI 4632-1 PLC Specification

Mounting Type
DIN rail mounting

Cable Length
Depends on sensor wiring, typically up to 30 m

Connectivity Type
Screw terminal, X20 bus

Weight
Approx. 62 g

Sensor Type
Compatible with analog sensors (voltage/current)

Application
Industrial automation, analog input signal acquisition

Processor Type
Not applicable - module for use with PLC CPUs

IP Rating
IP20

Remote Control
Yes

Load Capacity
Depends on module usage (input impedance: 1 M)

Control Type
Analog input module for PLCs

Automation Grade
Automatic

Frequency
50/60 Hz (influenced by application signals)

Features
4-channel differential analog input, configurable ranges, LED status indicators, hot swap capable

Material
Plastic housing, metal contacts, electronic components

Power
Supplied via the X20 system (typ. 1.5 W)

Temperature
-25C to +60C (operating), -40C to +85C (storage)

Voltage
24 V DC (supplied via bus module)

Storage Temperature
-40C to +85C

Clamp Connection
Removable terminal block

Configuration
Via Automation Studio software

Hot Swap Capability
Yes

Input Resolution
16 bit

Supported Input Signal
10V, 0-10V, 20mA, 0/4-20mA (configurable per channel)

Status Indicators
4 LEDs (module and channel status)

Module Width
24.5 mm

Input Impedance
Voltage: 1 M, Current: 100

Isolation
Channel to bus isolated, channel to channel not isolated

Number of Analog Inputs
4 (differential)

About B&R X20 AI 4632-1 PLC

B&R X20 AI 4632-1 PLC

B&R X20 AI 4632-1is an analog input module that features:

4 InputsIt includes 4 inputs with a 16-bit digital converter resolutionSignal SelectionUsers can select between current and voltage signals using different terminals.
Operating Temperature: It operates effectively in temperatures as low as -40C.
Configuration: The module is configurable for various applications, making it versatile for different industrial needs.

Flexible and Precise Signal Acquisition

The B&R X20 AI 4632-1 enhances your analog signal acquisition tasks by supporting both current and voltage signals on every channel. With 16-bit resolution and selectable input signal ranges, it is an ideal choice for high-precision measurement applications. Its differential input system minimizes noise, ensuring accurate data in demanding industrial environments.

Easy Integration and Maintenance

Integration with the X20 system is streamlined by easy configuration via Automation Studio software. The removable terminal block and screw terminal connectivity simplify installation and wiring. The module's hot swap capability allows for replacements without shutting down the system, maximizing uptime for industrial operations.

FAQ's of B&R X20 AI 4632-1 PLC:

Q: How do I configure the input signal range for each channel on the B&R X20 AI 4632-1?

A: Each channel's input signal range (10V, 0-10V, 20mA, 0/4-20mA) can be individually configured using B&R's Automation Studio software. This provides flexibility to match varied sensor outputs or application demands within a single module.

Q: What is the benefit of differential analog inputs on this module?

A: Differential inputs significantly reduce common-mode noise and electrical interference, resulting in more accurate analog signal acquisition, especially in environments prone to electrical noise or with long sensor cable runs.

Q: When is the hot swap feature useful, and how does it work?

A: Hot swap capability allows you to replace or add the X20 AI 4632-1 module without shutting down the control system. This minimizes operational downtime and is especially valuable during maintenance or module upgrades.

Q: Where can I mount the B&R X20 AI 4632-1 in my control panel?

A: The module is designed for DIN rail mounting, making it easy to install within standard control cabinets. Ensure it is placed within the environmental temperature range for optimal operation.

Q: What types of sensors are compatible with this analog input module?

A: The X20 AI 4632-1 is compatible with a wide range of analog sensors that output voltage (up to 10V or 0-10V) or current (20mA or 0/4-20mA) signals, making it suitable for most industrial analog measurement devices.

Q: How are status indicators used on the module?

A: The four onboard LEDs provide immediate visual feedback for module and channel status, which assists operators in quickly identifying normal operation or diagnosing faults without special equipment.
