ALLEN BRADLEY KINETIX 350 2097-V32PR2-LM DRIVE

Get a Price/Quote
MOQ : 1 Piece

ALLEN BRADLEY KINETIX 350 2097-V32PR2-LM DRIVE Specification

  • Application
  • Servo motor control for industrial automation
  • IP Rating
  • IP20
  • Processor Type
  • Integrated processor
  • Drive Type
  • Single-axis Servo Drive
  • Phase
  • Three Phase
  • Remote Control
  • Yes
  • Speed Range
  • 0 to 5000 rpm (motor dependent)
  • Connectivity Type
  • EtherNet/IP interface
  • Control Type
  • Digital Servo Drive
  • Sensor Type
  • Supports encoder feedback
  • Automation Grade
  • Automatic
  • Features
  • Integrated safety, compact size, support for multiple feedback types, plug-and-play EtherNet/IP connectivity.
  • Weight
  • Approx. 1.7 kg
  • Mounting Type
  • Panel Mount
  • Cable Length
  • Dependent on application and installation
  • Frequency
  • 50/60 Hz
  • Load Capacity
  • Up to 3 kW
  • Material
  • Industrial-grade components, Metal Enclosure
  • Power
  • 3 kW (rated output)
  • Temperature
  • Operating: 0 to 50C
  • Voltage
  • 200-240V AC, 3-Phase
  • Dimensions (H x W x D)
  • 230 x 60 x 195 mm (approx.)
  • Overload Capacity
  • 200% for 3 seconds
  • Cooling Method
  • Natural convection/air cooling
  • Input Current
  • 16.5 A (maximum)
  • Status Indicators
  • LED diagnostics for network, drive status, and safety
  • Control Modes
  • Position, Velocity, and Torque control
  • Software Compatibility
  • RSLogix 5000, Studio 5000
  • Feedback Supported
  • Incremental encoder, digital resolver
  • Braking Resistor
  • Integrated
  • Model Number
  • 2097-V32PR2-LM
  • Motor Support
  • VPL, MPL, TLY series servo motors
  • Communication Protocols
  • EtherNet/IP, CIP Motion



About ALLEN BRADLEY KINETIX 350 2097-V32PR2-LM DRIVE

ALLEN BRADLEY KINETIX 350 2097-V32PR2-LM DRIVE


The 2097-V32PR2-LM is a Kinetix 350 single-axis EtherNet/IP servo drive designed and manufactured by Allen-Bradley. The Kinetix 350 single-axis EtherNet/IP servo drive is intended for applications requiring output power ranging from 0.4 to 3.0 kilowatts ( 2 to 12 amperes rms).



Seamless Connectivity and Flexible Control

The KINETIX 350 drive provides EtherNet/IP and CIP Motion connectivity, allowing streamlined integration with modern PLC platforms. Its digital control lets you switch easily between Position, Velocity, and Torque modes for diverse automation needs.


Robust Performance in a Compact Footprint

Measuring only 230 x 60 x 195 mm and weighing 1.7 kg, this servo drive maximizes power in minimal space. With a 3 kW output, 200% overload for 3 seconds, and cooling by natural convection, it's engineered for demanding industrial environments.


Easy Setup and Reliable Operation

Supporting a wide range of feedback devices and offering integrated safety, the 2097-V32PR2-LM delivers plug-and-play operation with popular Allen Bradley software. Its LED diagnostics and IP20 enclosure further simplify maintenance and status checks.

FAQ's of ALLEN BRADLEY KINETIX 350 2097-V32PR2-LM DRIVE:


Q: How do I connect the KINETIX 350 2097-V32PR2-LM drive to my automation system?

A: You can connect the drive using the EtherNet/IP interface, enabling communication with compatible PLCs and controllers. Simply use standard Ethernet cables and configure your device in RSLogix 5000 or Studio 5000 software.

Q: What feedback devices are supported by this servo drive?

A: The KINETIX 350 supports incremental encoders and digital resolvers, providing flexibility in selecting the appropriate motor feedback for your application.

Q: When is it necessary to use the integrated braking resistor?

A: The integrated braking resistor is used during high deceleration or rapid stopping conditions. It safely dissipates excess energy generated by the motor while braking, protecting the drive and connected devices.

Q: Where should I mount the 2097-V32PR2-LM drive?

A: This drive is designed for panel mounting in an industrial enclosure. Ensure good ventilation and follow the recommended installation guidelines to maintain optimal cooling and performance.

Q: What is the process for configuring and commissioning the drive?

A: Configuring the drive involves connecting it via EtherNet/IP, selecting the correct control mode, and setting up motor and feedback parameters using RSLogix 5000 or Studio 5000 software. The user-friendly interface streamlines commissioning and diagnostics.

Q: What are the main benefits of using the KINETIX 350 single-axis servo drive?

A: Key advantages include compact size, integrated safety features, multiple feedback support, high overload capacity, and reliable plug-and-play communication with Allen Bradley PLCs, enabling efficient and scalable automation solutions.
