ALLEN BRADLEY 1734-FPD

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1734-FPD Specification

Application
Distributed I/O Systems, Field Power Distribution

IP Rating
IP20

Frequency
50/60 Hz

Control Type
Voltage Divider

Load Capacity
10 Amps per terminal

Weight
Approx. 50 grams

Features
Provides field power distribution across adjacent terminal bases, Removable terminal blocks for easy wiring, Support for horizontal or vertical mounting

Connectivity Type
DIN Rail Mounted Terminal

Automation Grade
Industrial Automation

Phase
Single Phase

Remote Control
Yes

Mounting Type
DIN Rail

Material
Plastic and metal

Power
Not Applicable (Passive device)

Temperature
Operating: -20C to 55C

Voltage
120/240V AC or 24V DC

Location
Between POINT I/O terminal base modules

Dimensions (H x W x D)
2.21 x 0.47 x 2.80 in (56.15 x 12 x 71.12 mm)

Wiring Terminal Type
Screw-terminal

Module Type
Field Power Distribution Module

Part Number
1734-FPD

Series
1734 POINT I/O

ALLEN BRADLEY 1734-FPD Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Packaging Details
AS PER CUSTOMER REQUIREMENT

Main Domestic Market
All India

About ALLEN BRADLEY 1734-FPD

ALLEN BRADLEY 1734-FPD

The 1734-FPD is a field-side voltage distribution module and a member of the Allen-Bradley PLC series that is engineered to break down field power distribution. Moreover, it has no power consumption, thermal dissipation, or power dissipation.

Versatile Power Distribution for POINT I/O Systems

The 1734-FPD module offers efficient field power distribution within your POINT I/O setup. Compatible with both 120/240V AC and 24V DC, its compact form factor and single-phase support make it perfect for industrial settings. The module seamlessly integrates between terminal base modules, providing reliable voltage separation and load capacity of 10 amps per terminal.

Simple Installation and Maintenance

Designed with practicality in mind, the 1734-FPD features screw-terminal connections and removable terminal blocks, making wiring straightforward. Whether mounted horizontally or vertically on a DIN rail, its user-friendly design allows technicians and engineers to modify, upgrade, or service distributed I/O systems with minimal effort.

FAQ's of ALLEN BRADLEY 1734-FPD:

Q: How does the ALLEN BRADLEY 1734-FPD facilitate field power distribution in POINT I/O systems?

A: The 1734-FPD module distributes incoming field power efficiently to adjacent terminal bases within POINT I/O systems by acting as a passive voltage divider. This setup enables separate power circuits or voltage groups, which helps manage power loads and enhances reliability in distributed applications.

Q: What types of wiring terminals does the 1734-FPD use, and how does this benefit installation?

A: This module is equipped with screw-terminal wiring and removable terminal blocks, simplifying both installation and future maintenance. These features allow quick, secure connections and easy replacement or changes to wiring without disturbing other components.

Q: When should you use the 1734-FPD in your distributed I/O system?

A: The 1734-FPD is ideal when field power needs to be isolated or distributed across specific terminal base modules or voltage groups within your POINT I/O array. Use it whenever segmentation of power supplies or management of different voltage levels is required.

Q: Where is the 1734-FPD typically mounted in an industrial automation setup?

A: This module is mounted between POINT I/O terminal base modules on a DIN rail within a control panel or enclosure. Its compact size and flexible orientation (horizontal/vertical) provide versatility for varied cabinet layouts.

Q: What is the process for integrating the 1734-FPD into an existing POINT I/O system?

A: To integrate the 1734-FPD, simply snap it onto the DIN rail at the desired location between terminal bases. Connect the incoming and outgoing field power through the screw-terminal blocks, then secure all wiring before restoring system power.

Q: What operational advantages does the 1734-FPD offer for industrial automation?

A: The module improves system safety and organization by clearly segmenting field power distribution. Its 10 amp-per-terminal load capacity, compatibility with multiple voltages, and ease of maintenance streamline I/O expansion and troubleshooting, contributing to overall productivity.
