ALLEN BRADLEY 1606-XL120D POWER SUPPLY

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1606-XL120D POWER SUPPLY Specification

Remote Control
Yes

Mounting Type
DIN Rail Mount

Connectivity Type
Terminal Block

Control Type
Electronic Control

IP Rating
IP20

Cable Length
Not Supplied

Application
Industrial Control Systems, Automation, Instrumentation

Load Capacity
5A at 24V DC

Frequency
47-63 Hz

Features
Overload Protection, Short Circuit Protection, Overvoltage Protection

Weight
0.9 kg (approx.)

Phase
Single Phase

Automation Grade
Industrial

Material
Metal Housing

Power
120W

Temperature
-10C to +60C (full power), -25C to +70C (with derating)

Voltage
Input: 85-264V AC, Output: 24V DC

Output Voltage Adjustment Range
24-28V DC

Parallel Operation
Yes

Efficiency
Typically 89%

Dimensions (HxWxD)
124 x 60 x 120 mm

Series
1606-XL

Inrush Current Limitation
Yes

Cooling
Natural Convection

Status Indicator
LED

Relative Humidity
5% to 95% non-condensing

About ALLEN BRADLEY 1606-XL120D POWER SUPPLY

ALLEN BRADLEY 1606-XL120D POWER SUPPLY

1606-XL120D, produced by Allen-Bradley, is a standard single-phase AC/DC power supply unit with a wide range of input voltage options and reliable output DC voltage value capable of boosting power up by 20% up to 6 Amps.

Compact, High-Efficiency Power for Industrial Automation

The 1606-XL120D combines a slim, lightweight build with powerful functionality. With up to 89% efficiency and a 120W output, it optimizes space while reliably powering demanding applications in industrial control, automation, and instrumentation. Its wide input voltage range and versatile installation options tailor it to Indian manufacturing and industrial scenarios.

Reliable Protection and Simple Operation

Engineered for resilience, the power supply offers overload, short circuit, and overvoltage protection. With an LED status indicator, electronic control, and support for parallel operation, it ensures system reliability and simplifies diagnostics. The absence of fans means silent operation and lower maintenance in harsh industrial settings.

FAQ's of ALLEN BRADLEY 1606-XL120D POWER SUPPLY:

Q: How do I install the ALLEN BRADLEY 1606-XL120D power supply in my control panel?

A: This power supply is designed for DIN rail mounting. Simply snap it onto a standard DIN rail in your control panel. Ensure secure connections to the terminal blocks for input and output wiring, and verify the LED indicator for operational status once powered.

Q: What are the benefits of the inrush current limitation feature?

A: The inrush current limitation protects connected components by preventing high surge currents during power-up, which reduces stress on upstream circuit breakers and extends the lifespan of both the power supply and other devices in your system.

Q: When should the output voltage adjustment range of 24-28V DC be used?

A: Adjust the output voltage within the 24-28V DC range when your application requires a voltage slightly above or below the standard 24V DC. This flexibility accommodates specific industrial equipment or compensates for voltage drops in long cable runs.

Q: Where is the 1606-XL120D typically used within industrial settings?

A: It is commonly deployed in industrial control systems, automation panels, and instrumentation setups across manufacturing, process industries, and infrastructure projects, especially where reliable, compact power delivery is essential.

Q: What process is involved in connecting loads to this power supply?

A: Connect your load to the output terminals, observing correct polarity and making sure the total load does not exceed 5A at 24V DC. Double-check connections, set the appropriate output voltage if needed, and confirm operation via the LED indicator.

Q: What are the main usage advantages of choosing this power supply?

A: Key advantages include its high efficiency, wide input range, multiple industrial protections, natural convection cooling for silent operation, and easy integration with DIN rail systems. These features ensure reliable, low-maintenance performance in challenging environments.
