ABB A43 212-100 ENERGY METER

Get a Price/Quote

MOQ : 1 Piece

ABB A43 212-100 ENERGY METER Specification

Connectivity Type
RS485 (Modbus)

Mounting Type
DIN Rail or Panel Mounting

Features
Multi-tariff, Programmable, Event Logging, Sealable terminal cover

Phase
Three Phase

Frequency
50/60 Hz

Processor Type
Microcontroller based

Remote Control
Yes

Screen Size
LCD Display, 8 digits

Application
Energy Measurement for Residential, Commercial and Industrial Installations

Load Capacity
100A (max)

Automation Grade
Automatic

Weight
Approx. 0.5 kg

Control Type
Digital

IP Rating
IP51 (front)

Material
Polycarbonate (Enclosure)

Power
Direct Connection (3x230/400V, 5(100)A)

Temperature
-25C to +55C (operating)

Voltage
230/400V AC

Display Type
Backlit LCD

Sealing Provision
Terminal and cover sealable

Accuracy Class
Class 1.0

Current Input
5(100)A

Data Retention
EEPROM (>10 years)

Compliance Standards
IEC 62052-11, IEC 62053-21

Impulse Output
LED and Pulse Output (S0 port)

Reference Voltage
230/400V AC

Communication Protocol
Modbus RTU

Power Consumption
<10VA/2W

Terminal Cover
Extended, Sealable

Event Recording
Last 100 events stored

Tariff Options
Up to 4 tariffs

Dimensions (W x H x D)
126 x 120 x 62 mm

About ABB A43 212-100 ENERGY METER

ABB A43 212-100 ENERGY METER

Advanced DIN-rail meter with a large and easy to read back lighted pixel-oriented display. The meter is intended for use in the industry, commercial buildings etc. The meter can be used in 3 or 4 wire systems with a wide voltage range. The meter has several instrumentation values, 25 possible alarms

and event logs. Three phase direct connected for active and reactive energy. Import and export of energy in different registers and one total. One output for pulses or alarm etc. RS-485 communication over Modbus RTU or EQ Bus. Accuracy class 1.0 (or B for MID meters). The meters is IEC approved + MID approved and verified.

Reliable Multi-Tariff Energy Measurement

The ABB A43 212-100 enables organizations to assign up to four tariffs, making it ideal for dynamic pricing models common in commercial and industrial energy management. Its high-accuracy, microcontroller-based system ensures precision in monitoring and billing, contributing to cost efficiency and improved energy utilization.

Comprehensive Event Logging and Data Retention

The built-in EEPROM secures consumption and event data for over 10 years, preserving the history of the last 100 events. This capability supports audit trails, diagnostics, and compliance for energy usage reporting in rigorous operational environments.

Flexible Installation and Communication Options

Designed for easy DIN rail or panel mounting, the meter's compact dimensions and extended sealable terminal cover provide adaptability and security. With support for Modbus RTU protocol over RS485, seamless integration into building management or SCADA systems is straightforward.

FAQ's of ABB A43 212-100 ENERGY METER:

Q: How does the ABB A43 212-100 record and store energy consumption data?

A: The energy meter utilizes an EEPROM for robust data retention, storing consumption information and the last 100 recorded events securely for over 10 years. This ensures access to historical energy data for audits, analysis, and compliance purposes.

Q: What tariff management capabilities does this meter offer for energy billing?

A: The ABB A43 212-100 supports up to four configurable tariffs, allowing users to track and bill energy consumption based on different time-of-use rates or operational schedules, optimizing energy costs for residential, commercial, or industrial applications.

Q: When is Modbus RTU communication beneficial for users?

A: Modbus RTU protocol allows for effective remote data acquisition and integration with automation systems. Users can implement real-time monitoring, centralized energy management, and streamlined reporting by utilizing the RS485 connectivity feature of this meter.

Q: Where can the ABB A43 212-100 be installed, and what are its mounting options?

A: This meter is suitable for DIN rail or panel mounting, making it adaptable for a range of installations in residential, commercial, and industrial environments. Its compact form and sealable terminal cover enhance flexibility and security during deployment.

Q: What is the process for ensuring the security of meter connections?

A: The meter has provisions for sealing both the terminal and cover, deterring unauthorized access and tampering. Extended terminal covers and polycarbonate housing add further physical security, fulfilling regulatory and operational requirements.

Q: How does the device handle different operational environments?

A: Engineered for versatility, the meter operates reliably between -25C and +55C with an IP51 rated front. This enables robust performance in varied climatic conditions, making it suitable for deployment across diverse geographical locations.

Q: What are the key benefits of using the ABB A43 212-100 for energy measurement?

A: Users benefit from precise metering, programmable multi-tariff support, event logging, secure data retention, and seamless integration with management systems. These features drive regulatory compliance, operational transparency, and cost-effective energy management.
